DuplexFiber Optic Cable — Zipcord Indoor
Dual-fiber zipcord indoor cable (ZCC) with two 900um tight-buffered fibers in a figure-8 shaped PVC or LSZH jacket. Available in 2.0mm and 3.0mm per unit, SM 9/125 and MM 50/125. Easy to separate for individual connector termination.
Technical Specifications
Engineered For Performance
Figure-8 Zipcord Design
Integrated figure-8 profile allows easy separation of the two fiber units for individual connector termination while maintaining a single cable for neat routing.
Duplex Bi-Directional Transmission
Two independent fibers enable simultaneous transmit and receive over a single cable run, standard configuration for most network switch and transceiver connections.
Easy Peel & Branch
The 8-shaped structure peels apart cleanly at any point along the cable, simplifying installation where fibers need to route to different ports or equipment.
Color-Coded Identification
Yellow jacket for single-mode (OS2), orange for OM1/OM2, and aqua for OM3/OM4 multimode. Consistent color coding across all duplex cable products.
Typical Applications
Duplex Patch Cord Assembly
Standard cable for manufacturing LC-LC, SC-SC, and other duplex patch cords used in data center and enterprise network connections.
Workstation Connections
Desktop fiber connections from wall outlets to workstation network interface cards, providing dedicated transmit and receive fiber paths.
Switch-to-Switch Links
Short-range duplex fiber links between network switches, routers, and SFP transceivers in structured cabling environments.
Interested in this Duplex Fiber Optic Cable?
Tell us your quantity, cable length, and any custom requirements. Our engineering team will respond with a detailed quote within 24 hours.
