Distribution fiber optic cable multi-core with color-coded tight-buffered fibers
Distribution fiber cable cross-section showing 900um sub-units in common jacket
Indoor Fiber Optic Cable

DistributionFiber Optic Cable — Indoor Riser

Indoor distribution fiber cable with multiple 900um tight-buffered sub-units in a common outer jacket. 6-72 cores with riser (OFNR) and plenum (OFNP) rated options. Compact design for building backbone and horizontal distribution cabling.

Cable TypeIndoor Distribution Cable
Fiber Count6-72 cores
Fiber TypeG.652D SM 9/125 / OM1-OM4 MM 50/125
Sub-Unit Diameter900um tight buffer
Cable Diameter5.0mm (6-core) to 18.0mm (72-core)
Jacket MaterialPVC or LSZH
Specifications

Technical Specifications

Cable Type
Indoor Distribution Cable
Fiber Count
6-72 cores
Fiber Type
G.652D SM 9/125 / OM1-OM4 MM 50/125
Sub-Unit Diameter
900um tight buffer
Cable Diameter
5.0mm (6-core) to 18.0mm (72-core)
Jacket Material
PVC or LSZH
Fire Rating
OFNR (riser) / OFNP (plenum)
Strength Member
Aramid yarn / FRP central member
Weight
20-250 kg/km
Tensile Strength
130-450N (short-term)
Crush Resistance
300-1000N/100mm
Bend Radius
100mm (static) / 200mm (dynamic)
Operating Temperature
-20C to +60C
Standards
YD/T 1258.4 · ICEA-596 · GR-409 · IEC 60794-2-10/11 · TIA-568
Key Features

Engineered For Performance

Compact Multi-Fiber Design

Multiple 900um tight-buffered fibers in a single jacket provide higher fiber density than breakout cables while maintaining direct access to individual fibers for termination.

Riser & Plenum Rated

Available in OFNR (riser) and OFNP (plenum) fire-rated versions, meeting NEC requirements for installation in building risers and air-handling spaces.

Easy Mid-Span Access

Common jacket design allows mid-span cable entry to access individual fibers at any point along the cable run, simplifying multi-floor distribution installations.

Standard Color Coding

All fibers color-coded per TIA-598 standard for reliable identification. Available in single-mode (yellow), OM1/OM2 (orange), and OM3/OM4 (aqua) configurations.

Typical Applications

01

Building Riser Backbone

Vertical fiber backbone in multi-story buildings, connecting the main distribution frame in the basement to telecommunications rooms on each floor.

02

Horizontal Distribution

Floor-level fiber distribution from telecommunications closets to work area outlets, supporting enterprise LAN and data center structured cabling.

03

Data Center Backbone

Intra-facility fiber backbone connecting main distribution areas to horizontal distribution areas within data centers and large enterprise network environments.
