E2000Fiber Optic Pigtail — Single Mode UPC & APC with Dust Cap
E2000 fiber optic pigtail with integrated spring-loaded dust cap for automatic ferrule protection when disconnected. Available in UPC and APC polish types for single mode 9/125μm applications. 0.9mm tight buffer with high-precision 1.25mm ferrule. Widely used in European telecom networks and high-security optical installations requiring contamination-free connections.
Technical Specifications
Engineered For Performance
Automatic Dust Cap Protection
Integrated spring-loaded dust cap automatically covers the ferrule end face when the connector is unplugged, preventing contamination without requiring separate dust caps.
High-Security Laser Safety
E2000 connector design includes built-in laser eye safety features, blocking laser light emission when disconnected — meeting strict European safety regulations.
LC-Compatible Form Factor
1.25mm ferrule provides the same compact density as LC connectors, while the integrated dust cap adds contamination protection for demanding telecom environments.
UPC & APC Polish Options
Available in standard UPC (≥55dB RL) for general applications and APC (≥60dB RL) for CATV, PON, and high-sensitivity optical systems requiring minimal back-reflection.
Typical Applications
European Telecom Networks
E2000 pigtails are standard in many European telecom operators' specifications for central office equipment, ODF termination, and subscriber access splicing.
High-Security Optical Installations
Military, government, and financial institution fiber networks where built-in dust protection and laser safety features are required by facility security policies.
Clean-Room & Medical Fiber
Self-protecting dust cap design is ideal for medical imaging, laboratory instrumentation, and clean-room fiber connections where contamination must be minimized.
Interested in this E2000 Pigtail?
Tell us your quantity, cable length, and any custom requirements. Our engineering team will respond with a detailed quote within 24 hours.
