48-port fiber distribution box front view with lockable door
48-port fiber distribution box open showing 48 SC adapters and splice trays
Fiber Optic Distribution Box

48-Port Fiber Distribution Box — Large FTTH Indoor/Outdoor

48-port fiber distribution box for large-scale FTTH deployments. Dual-use indoor/outdoor design with IP55 protection. Pre-terminated with PLC splitter option for rapid deployment. Cold rolled steel construction with lockable front door for security.

Port Count48
Adapter TypeSC, LC
MaterialCold Rolled Steel (1.2mm)
Operating Temperature-40°C to +65°C
Specifications

Technical Specifications

Port Count
48
Adapter Type
SC, LC
Material
Cold Rolled Steel (1.2mm)
Protection Rating
IP55 (indoor/outdoor)
Mounting
Wall mount
Splice Tray
4 trays, 48 core capacity
Splitter Support
Up to 2x 1x32 PLC splitters
Cable Entry
4 inlets, 48 outlets
Dimensions
560 x 420 x 160mm
Door Type
Hinged with key lock
Operating Temperature
-40°C to +65°C
Standards
IEC 61753 · IEC 61300 · YD/T 2000
Key Features

Engineered For Performance

High-Capacity 48-Port Design

48-port capacity serves high-density residential complexes and commercial buildings from a single distribution point, reducing the number of enclosures needed in the network.

Indoor/Outdoor Dual-Use

IP55 protection with sealed cable entries and lockable steel door allows deployment in both indoor equipment rooms and sheltered outdoor locations.

Pre-Terminated with PLC Splitter

Available pre-terminated with pigtails and up to two 1x32 PLC splitters, enabling one-step installation that reduces field labor and splice time.

Lockable Steel Enclosure

1.2mm cold rolled steel body with hinged lockable door protects fiber connections from unauthorized access and accidental damage in shared or public spaces.

Typical Applications

01

Large Apartment Complex FTTH

Centralized fiber distribution for large apartment buildings, serving up to 48 residential units from a single basement or ground-floor enclosure.

02

Commercial Building Fiber Hub

Fiber distribution hub in commercial buildings where multiple office tenants require dedicated fiber connections from a shared building entry point.

03

Multi-Dwelling Unit (MDU) Distribution

Floor-level or building-level distribution box in MDU FTTH projects, consolidating splitter and termination functions in one enclosure.

Interested in this 48-Port Distribution Box?

Tell us your quantity, cable length, and any custom requirements. Our engineering team will respond with a detailed quote within 24 hours.
