MPOFiber Optic Adapter — Key-Up/Key-Down for High-Density Patching
MPO/MTP fiber optic adapter for connecting two MPO-terminated multi-fiber cables. Available in key-up to key-down (Type A) and key-up to key-up (Type B) configurations. Supports 12-fiber and 24-fiber MPO connectors for 40G, 100G, and 400G high-density data center patching.
Technical Specifications
Engineered For Performance
Polarity Management
Key-up to key-down (Type A) and key-up to key-up (Type B) options enable correct polarity management across structured cabling systems following TIA-568 guidelines.
SC Footprint Compatibility
MPO adapters fit standard SC adapter panel cutouts, allowing direct installation in existing patch panels and cassettes without hardware modification.
12/24 Fiber Support
Compatible with both 12-fiber and 24-fiber MPO/MTP connectors, supporting parallel optics from 40G (SR4) through 400G (SR8) data center architectures.
Color-Coded Key Orientation
Black housing for standard key-up/key-down and green housing for key-up/key-up configurations enable quick visual identification and prevent polarity errors during installation.
Typical Applications
Data Center Spine-Leaf Cabling
MPO adapters in high-density cassettes and panels connecting 40G/100G/400G QSFP and OSFP transceivers in leaf-spine and mesh data center architectures.
MPO Patch Panel Systems
Pre-loaded MPO adapter panels for rapid deployment of structured multi-fiber cabling in colocation facilities, cloud data centers, and enterprise server rooms.
Network Testing
MPO adapters in test setups for verifying insertion loss, polarity, and continuity of MPO trunk cables and harness assemblies before deployment.
Interested in this MPO Adapter?
Tell us your quantity, cable length, and any custom requirements. Our engineering team will respond with a detailed quote within 24 hours.
